English POWER SUPPLY
CONTROLS MAINS ADAPTER
©
©
©
©
©
®
®
POWER - radio on/off
ALARM - alarm on/off
TONE - sound
VOLUME - sound level
PRESET buttons - to select pre-selected sta­
tions
© TUNING buttons with tuning dials - to set
pre-selected stations
MODE switch - to set correct time and alarm
time
CLOCK setting knob - to set hands of clock
connection for 6 V mains adapter
connection for loudspeaker
battery compartment
This product complies with the radio interference
requirements of the European Community.
The type plate is in the battery compartment.
MOUNTING_________________________________
The tray of the appliance can be mounted on a wall
or underneath a shelf. The mounting material
required for this is supplied. Once the tray is
secured, slide the radio clock into it.
On a wall (see fig. 4)
• Make holes with a screwdriver through the
mounting holes located on the back of the tray.
• Screw the tray to the wall.
Under a shelf (see fig. 5)
• Make holes with a screwdriver through the
mounting holes on the top of the tray.
• Screw the tray to the shelf.
To attach aerial (see fig. 3}
• Clamp the excess wire from the aerial under the
screw on the back of the appliance.
• After you have mounted the tray, take the wire
through the hole on the back of the tray. A space
has been left here, so that the wire cannot be
pressed against the wall.
The radio can be connected to the mains via the
enclosed 6 V D C mains adapter. This adapter
supplies 6V direct current with the negative
terminal' — ’ to the central pin.
• Check that the operating voltage of the adapter
is the same as the local mains voltage.
• Insert the plug of the mains adapter into the
6 V DC connection socket ®.
• Connect the adapter to the wall socket.
• In changing over from mains supply to battery
supply, the plug must be withdrawn from 6 V DC
socket ®, otherwise the battery supply will remain
disconnected.
Important note for users In U.K:
When fitting a mains plug to the mains lead proceed as follows:
The wires in the mains lead are coloured in accordance with the
follovnng code: Blue=Neutral. Brown=Live.
These colours may not correspond wnth the colour markings
identifying the terminals in your plug, so proceed as follows:
Connect the Brmvn wire to the terminal marked Lor coloured Red.
Connect the Blue wire to the terminal marked Nor coloured Black.
No connection is necessary to the earth terminal.
Note: This apparatus must be protected by a 3 Amp Fuse if a
13 Amp plug is used or, if any other type of plug is used, by a 5 Amp
Fuse either in the plug or adapter or at the distribufion board. If in
doubt consult a qualified electrician.
Warning: When this unit is not in use and also before attempting
internal examination, remove the mains plug from the wall sockeL
BATTERIES__________________________________
One battery of type R6, UM3 or AA is required for
the clock. The radio can operate on 4 batteries of
type R20, UM1 or D.
• Insert the batteries in compartment ® (see
fig. 2).
Recommendation
Replace the batteries at least once a year. If you will
not be using the appliance for any length of time, it
is also advisable to remove the batteries from the
appliance, to avoid the possibility of leakage and
consequently damage to the appliance.
