Philips AZ7361 - Manual (Page 2)

Ils l{JB
Ч гвв
Playing a CD
1
Open the lid by pushing the OPEN slide control to
the side.
2 Insert an audio CD, printed side up.
3 Close the lid by pushing down on the right-hand side.
-► Display indication of: (example)
17 = total number of tracks / 51:06 = total playing
time.
4 Press the HI button to start CD play.
-► Display indication of; (example)
4 = current track / 2:56 = elapsed time of current
track
5 Adjust the sound using the controls VOLUME and DBB.
6 You can interrupt CD play by pressing the HI button. Continue CD play by
pressing the ►II button again.
-► Display indication of: time of the current position (flashing).
7 Press the STOP ■ button to stop CD play.
Display indication of: total number of tracks / the total playing time.
• If you press the STOP ■ button again, you will switch off the set.
Note: If no button is pressed for 90 seconds, the set will switch off auto­
matically.
and ►►
Selecting another track
• Briefly press the or button once/several times
• ■ to skip to the beginning of the current/previous or-—
next track(s).
-► Display indication of: selected track number.
-► During play: CD play continues automatically with the selected track.
-► In stop position: press the ►!! button to start CD play.
Searching for a passage during CD play
1 Hold down the or button to find a particular passage in forward or
backward direction.
After 2 seconds, searching will start at high speed.
2 Release the button when you have reached the desired passage.
Note: Searching is only possible within the particular track when you are
in one of these modes: SHUFFLE, REPEAT 1 or PROGRAM.
Searching is not possible in the SCAN mode.
MODE О - different playing modes
• By pressing the MODE О button, you can
successively activate the playing modes:
SHUFFLE; The tracks are played in random order
until all of them have been played once.
SHUFFLE REPEAT ALL: All tracks are played repeatedly in random order
until you leave this mode.
REPEATT; The track is played repeatedly untW you leave this mode.
REPEAT ALL: The CD is played repeatedly mXW you leave this mode.
SCAN; Each track is scanned for 10 seconds until you leave this mode or
all tracks have been played once.
-► The selected playing mode is indicated in the display.
-►During play: CD play continues automatically with the selected playing mode.
-► In stop position: press the ►!! button to start CD play.
Notes:
- You can choose from 12 different playing modes when you combine all the
above-mentioned modes with PROGRAM.
- Deactivate all modes with the MODE О button.
PROG - programming of tracks (max. 25 tracks)
1 Select the desired track with PREV ги or NEXT ►«.
2 As soon as the desired track is displayed, press the PROG button to store
the track in the memory.
-► Display indication of: track number
IP/ total number of stored tracks, e.g.
S РОЗ
Cl I, ,
I uLL
S t i E C b
Notes:
- When you try to store more than 25 tracks,
the display indicates FUL L .
- When you press PROG and there is no track
selected, the display indicates S E L E C t .
Playing the^o^ratn: te.,.
• If you have selected the tracks in STOP mode, press the PLAY/PAUSE ►!!
button.
• If you have selected the tracks during CD play, first press STOP ■ and
then the PLAY/PAUSE HI button.
-► Display indication: PROGRAM.
-► Your program will be played in the selected playing mode (e.g. shuffle).
Reviewing the settings:
• Press the PROG button for more than 2 seconds.
-► Display indication; each stored track successively flashes for a short
moment.
Erasing the program in STOP mode:
• Press the STOP ■ button to erase the program.
-► PROGRAM disappears on the display and your program is erased.
E R F lights up briefly on the display.
Note: Interrupting the power supply or opening the lid will also erase the
program.
ESA - Electronic Shock Absorption Memory
• Activate the ESA memory by sliding the ESA switch
to the right.
-► The ESA symbol lights up in the display.
-► The ESA memory continuously stores in advance
the CD data to be played. This is to prevent sound
skipping during play due to shock and vibration.
-► Prolonged shocks and vibrations may empty the ESA memory comple­
tely. Then the display shows S O T i H and there will be no sound.
Note: When switching the ESA feature on and off, CD play will be delay­
ed or interrupted for a short time.
RESUME - playing from where you have stopped
• Activate the RESUME feature by sliding the
RESUME/HOLD switch to the middle.
If you stop CD play by pressing the STOP
I
the last played position will be stored.
button.
• Press ►!! to resume CD play from the position where it was stopped.
HOLD - deactivating ail buttons
• Activate the HOLD feature by sliding the RESUME/HOLD switch to the far
right.
-► Now all buttons are deactivated and will not function until you switch
the feature off again, if you press a button (except OPEN), the display
will indicate HOLD.
Notes:
-In the HOLD position, the RESUMEfunction is automatically activated.
-Do not open the lid as this erases the information about the last position played.
TROUBLESHOOTING : • 1
• If a fault occurs, please check the points listed below before taking your
set for repair.
• If you are not able to remedy a problem by following these hints, consult
your dealer or service facility.
PROBLEM POSSIBLE CAUSE SOLUTION
No power or no
CD play start Batteries
Batteries incorrectly inserted Insert the batteries correctly
Use of new batteries Press ►!!
Display: Batteries are empty Change/recharge the batteries
no indication Contact pins are dirty Clean them with a cloth
mains adapter
Loose connection Connect the adapter securely
In car use
Cigarette lighter is not
poweredwhen ignition
is switched off
Switch on ignition or
insert batteries
CD play does not HOLD feature is activatedSwitch off the HOLD feature
start or interrupts CD lid is not closed securely Close the lid securely
Moisture condensation Leave the olayer in a warm
place until the moisture
evaporates
Display; no
indication CD is not or incorrectly
inserted
Insert a CD, label facing up
or no d ¡SC CD is badly scratched Use another CD
CD is dirty___________________ Clean the CD
Battery-recharging Use of wrong batteries,,________
on board does not
Onjy a_batte_[y pack can
be recharged on board
work, no CHARGE- Contacts are dirty
indication
Clean them with a cloth
Play does not start RESUME or SHUFFLE or
from the first track PROGRAM is activated
Switch off RESUME, SHUFFLE
or PROGRAM
No sound or bad PAUSE is activated Press ►!!
sound quality Loose or wrong connections Check connections
Volume is not turned up Adjust the volume
Headphones worn the
wrong way
Pay attention to the L (left)
and R (right) indications
Headphone plug is dirty Clean the headphone plug
Strong magnetic fields near
the CD player
Change the player’s position
or connections
Electrostatic discharge from
the user via the CD player
Press V« or once or
press ►!! twice
In car use
Strong vibrations Rnd another place for the set
■ Adapter cassette is
incorrectly inserted
Insert the adapter cassette
correctly
Temperature inside caris
too high/low
Let the CD player adjust to
the temperature
Cigarette lighter/socket is
too dirty
Clean the cigarette
lighter/socket
Wrong playback direction of Change the autoreverse
the autoreverse feature of direction
the car cassette player
Hum or noise in car Unfit car radio input socket Use the adapter cassette
