background image

TVN 21(S/P) Quick Start Guide

5 : EN

Name

Description

Tour: In PTZ control mode, press Tour and a numeric button to call up

preprogrammed shadow tours.

7.

IR receiver

Receiver for IR remote control.

8.

Playback buttons

Reverse: In live view, play the earliest video file of the current camera;

In video playback mode, playback a camera in reverse direction; In picture

playback mode, view pictures in reverse direction.

Pause: In live view mode, freeze the last image of of the live display

for all cameras in the selected display mode. In playback mode, stop playing

the video.

Play: In live view mode, play all-day playback of the current camera

(upper left video tile if in multiview mode); In playback mode, play back a

camera in the forward direction; In search mode, play back a selected video

or view a snapshot; In PTZ mode, do an auto tour. See the user manual for

more information.
Instantly playback the currently selected file. Default time is 1 minute.
Live: Switch to live view mode. Hold for five seconds to lock or unlock the

front panel.
Replay: In playback mode, start play back at the beginning of the file in the

current display mode.

9.

Menu and Search

buttons

Menu: Enter/exit the main menu.
Search: In live view mode, enter the advanced search menu.

10. Front panel lock

You can lock or unlock the front panel with a key.

11. Display buttons

Display: Toggle through the various multiviews: full, quad, 1+5, 1+7, 9, and

16.
Seq: Start/stop sequencing cameras on the current monitor.
A: In live view mode, select the main monitor.
B: In live view mode, select the event monitor.
F1: In playback mode, click to start and stop video clipping.
F2: In live view, all-day playback and playback modes press to display/hide

the time or control bar. In PTZ mode, stop all ongoing operations.

Package contents

The TruVision NVR 21(S/P) (model TVN 21

(S/P) is shipped with the following items:
• IR (infrared) remote control
• Two AAA batteries for the remote

control

• AC power cords (US, Europe, UK)
• USB mouse
• NVR
• CD with software and manuals
TruVision NVR 21(S/P) Quick Start

Guide

TruVision NVR 21(S/P) User Manual

(on CD)

TruVision Recorder Operator Guide (on

CD)

Installation environment

Refer to the user manual for detailed

information, but observe these important

requirements:
• Place the unit in a secure location.
• Ensure that the unit is in a well-

ventilated area.

• Do not expose the unit to rain or

moisture.

Quick install

Recommended steps for setting up the

recorder

:
