Interlogix VDP-B Series - Manual (Page 2)

Technical Specifications*
Electrical
Video Format NTSC, PAL, SECAM
Frequency DC to 10 MHz
Coax 75 Ohm
Twisted Pair 100 Ohms +/- 20%, 24 AWG MINIMUM Category 2-7
Input Voltage Pass through (GEC-VCR and GEC-VDPBC)
30 – 16 VAC/DC, Class II SELV (GEC-VCR12V)
Output Voltage 12 VDC Regulated, 30 mV ripple maximum (GEC-VCR12V)
Output Power 600 mA maximum (GEC-VCR12V)
Insertion Loss 0.3 dB
CMRR 60 dB
Connectors UTP: RJ-45 connector
Data: 9 in. twisted pair
Power: 9 in. twisted pair
Video: BNC connector (GEC-VCR and GEC-VCR12V)
9 in. pigtail coax and male BNC (GEC-VPDBC)
Mechanical
Material ABS plastic, UL rating 0f 94V-0
Dimensions (W x H x D) GEC-VCR: 0.88 x 0.88 x 0.68 in. (2.3 x 2.3 x 1.72 cm)
GEC-VDPBC: 0.72 x 2.3 x 0.7 in. (1.8 x 5.8 x 1.77 cm)
GEC-VCR12V: 1.25 x 1.5 x 0.8 in. (7.1 x 3.8 x 2 cm)
Weight GEC-VCR: 0.08 lb. (35 g)
GEC-VDPBC: 0.06 lb. (25 g)
GEC-VCR12V: 0.09 lb. (40 g)
Environmental
Humidity 0 to 95%, noncondensing
Temperature Operating: -10° C to +50° C
Storage: -30° C to +70° C
*Specifications are subject to change without notice.
Regulatory information
Manufacturer GE Security, Inc.
HQ and regulatory responsibility:
GE Security, Inc., 8985 Town Center Parkway,
Bradenton, FL 34202, USA
EU authorized manufacturing representative:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands
Regulatory
information N4131
Note: C-Tick mark applies to model GEC-VCR12V
North American
standards UL 60065
FCC Compliance This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
2002/96/EC (WEEE directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For
proper recycling, return this product to your local supplier upon the
purchase of equivalent new equipment, or dispose of it at designated
collection points. For more information see: www.recyclethis.info.
