ifs
International
Fiber
Systems
Incorporated
VT7430
4 CHANNEL DIGITAL
VIDEO TRANSMITTER
POWER
VIDEO
INPUT
OPTICAL OUT
Simplex single mode
fiber optic cable
4 BNC Cables
(Fixed Video Inputs from Cameras)
4 BNC Cables
(Video Output to Monitors)
ifs
International
Fiber
Systems
Incorporated
VR7430
4 CHANNEL DIGITAL
VIDEO RECEIVER
1 -
2 -
3 -
4 -
VIDEO
OUTPUT
OPTICAL INPUT
CAMERA ON
- 2
+12 VDC - 1
POWER
- 2
+12 VDC - 1
POWER
1
2
3
4
NOTE: When the VT7400 Series is set in a rack (-R3) configuration, there is an additional set
of four (4) BNC connectors. These additional connecttors allow for the video inputs to be inserted
from the front OR back of the unit BUT NOT BOTH.
POWER RECEIVER
LOCKED
CHANNEL 1
CHANNEL 2
CHANNEL 3
CHANNEL 4
REMOTE VIDEO ON
LOCAL VIDEO ON
