Interlogix VR7200 Series User Manual
Page 2

ifs
International
Fiber
Systems
Incorporated
VT7230
2 CHANNEL DIGITAL
VIDEO TRANSMITTER
POWER
VIDEO
INPUT
OPTICAL OUT
Simplex single mode
fiber optic cable
2 BNC Cables
(Fixed Video Inputs from Cameras)
2 BNC Cables
(Video Output to Monitors)
ifs
International
Fiber
Systems
Incorporated
VR7230
2 CHANNEL DIGITAL
VIDEO RECEIVER
1 -
2 -
VIDEO
OUTPUT
OPTICAL INPUT
- 2
+12 VDC
- 1
POWER
- 2
+12 VDC
- 1
POWER
1
2
CAMERA ON
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.
