ifs
International
Fiber
Systems
Incorporated
VR1500WDMCC
VIDEO RECEIVER
+
DATA TRANSMITTER
+
CONTACT CLOSURE
-2
+12 VDC -1
NC - 6
NC - 5
RELAY CONTACT - 4
-DATA -3
-2
+DATA -1
OPTICAL
IN/ OUT
VIDEO OUT
POWER
VIDEO OUT / AGC
RS232
RS422
ifs
International
Fiber
Systems
Incorporated
VT1500WDM
VIDEO TRANSMITTER + DATA RECEIVER D -4
GND -3
+ D -2
- D -1
12 VAC/ 12 VDC - 3
GRD - 2
12 VAC/ 12 VDC - 1
VIDEO IN
OPTICAL IN/OUT
POWER
RS232
DATA
OUT
RS422
POWER
Simplex multimode
fiber optic cable
Coax cable
Video source
Video
monitor
VIDEO PRESENT
DATA RECEIVE
CONTACT CLOSED
DATA IN
POWER
