AR2000
AUDIO INPUT
NOTE: For an unbalanced connection, tie pin 2 to pin 3 and utilize pins 1 and 2 for the audioinput to the AR2000 Series module. Utalize pins 4 and 5 for the audio output from the AR2000 Series module.
654321
Audio Input
Ground
Audio Output
AUDIO OUTPUT
