NVR8128
Head Office
IC Realtime
3050 N Andrews Ave Ext.
Pompano Beach, FL 33064
Tel: 1 (866) 997.9009
Fax: 1 (954) 827.5900
Email: [email protected]
West Coast Office
IC Realtime
14180 W. Van Buren St.
Suite B105
Goodyear, AZ 85338
Tel: 1 (602) 910.3432
Fax: 1 (602) 6263545
Email: [email protected]
Display
Interface
Video Outputs: 1 Primary VGA (64 camera view), 1 Primary HDMI (64 camera view), 5
Secondary HDMI (single or quad view)
Video Output
Video Outputs: 1 Primary VGA (64 camera view), 1 Primary HDMI (64 camera view), 5
Secondary HDMI (single or quad view) (or built-in LCD)
Multi-screen Display
The 1st screen: 1/4/6/8/9/16/32/64 The 2nd-6th screens: 4
Privacy Masking
Four customized zones for privacy masking for each area
Hard Drive
Hard Disk
16 SATAII
HDD Mode
Single, Raid 0, Raid 1, Raid 5. (Support global HDD Hot-standby) (Optional)
HDD Installation
Independent HDD rack, support hot swap
Network
Interface
4 RJ-45 ports(10/100/1000M)
Ethernet Port
4 Ethernet ports joint working or 4 independent 1000M Ethernet ports
MD & Alarm
Motion Detection
Zones: 396(22x18), Sensitivity: 1~6 (level 6 is highest)
Alarm Input
16ch, low level effective, green terminal interface
Relay Output
8ch, Relay contact(1A@24VDC), NO/NC programmable, green terminal interface
Interface
Front cover
Support hot swap, 7" inch HD LCD (1920 x 1080 / 1280 x 1024 / 1024 x 768)
USB
4 USB ports(2 on the front-panel, 2 on the rear panel)
eSATA
1 eSATA (Used for manual backup storage only)
Supported IPCs
