2
Model
Parameter
1 Megapixel HD-AVS Analog Camera
AVS-D2110 AVS-B2100 AVS-B2110
Video Processor 1/3" 1.3 Megapixel CMOS
Video Format PAL/NTSC
Effective Pixel 1280(H)×960(V)
Min Illumination
Color: 0.01Lux/F1.2（0 Lux with IR）
Electronic Shutter PAL：4/25s～1/45,000s
NTSC：4/30~1/54,000s
Video Standard
HD-AVS/CVBS compliance
Video Frame Rate 1280×720@25 fps；1280×720@30 fps；
1280×720@50 fps；1280×720@60 fps
Lens Port
M12
Lens Type
2.8/3.6/6/8mm optional
Day/Night Switch
ICR mechanical auto switch
Video Output 1-channel BNC analog high definition video output/ CVBS analog standard
definition video output (Can switch.)
Denoise (Noise
Reduction)
Support 3D denoise.
OSD Menu Control
Support
OSD EXPOSURE Global/centre/Centre weight/BLC/Front light/Distinguish
WHITE
BALANCE
AWB-GW/AWB-CCT/AWB-PRO/AWB-TEMPROAL/AWB-AI/AWB-SZ
DAY/NIGHT Auto/B&W/Color
FUNCTION 3DNR
ADVANCED Mirror/Language/RS485/Video format/Version/
IMAGE Sharpness/Contrastness/Saturation/Brightness
EXIT SAVE/CANCEL/RESET
Max IR Distance 20m 30 m 20 m
Transmission
Distance
Over 500m via 75-3 coaxial cable.
Protection Level IP66
Working Temperature
/Humidity
-30
℃~+60℃. Humidity is less than 95%(no condensation)
Power
DC 12V±10%
Power Consumption 3.5W MAX (Input:
12V
0.29A)
6W MAX
(Input: 12V
0.5A)
4.2W MAX
(Input: 12V
0.35A)
Dimension(mm)
Φ113.6Ч85.4 200.2Ч89.1Ч80.4 φ65.0×154.7
Weight 300g 450g 380g
Installation Mode Wall mount
In-ceiling mount Wall mount
