User-accessible components – Cabletron Systems 9T122-24 User Manual
Page 16
Installation
2-4
User-Accessible Components
Figure 2-3 shows the various components that are accessible to the user. These
consist of an eight-position dip switch (explained in the next section), replaceable
PROMs and sockets for RAM. These will be used for future upgrades.
Figure 2-3. User Accessible Components
SMB-1 PROM
i960 Processor
Flash SIMM
Socket
DIP Switch
Boot PROM
Local Program Memory
SIMM Socket
Shared Packet
Memory SIMM
