6
Specifications
Speaker System (PI30, PI30-PS and PI30-SP)
Power Capacity 30 Watts RMS power capacity, 6 Ohms impedance
Sound Pressure Level: 93 dB, 1 Watt @ 1 Meter
Dispersion: -3dB @ 120 degrees off axis
Frequency Response: 250Hz to 12KHz
Transducers: Three each 3.5” Diameter, High Energy Neodymium Magnets,
10 Watts RMS capacity 3/4” Dia. Voice Coil, 16 Ohm
Amplifier: 15 Watts RMS @ 5% THD
Power Source: 100-240 volt AC universal power supply
12 VDC to amplifier
Dimensions: 12” H x 5” W x 4” D
Weight:
Speaker 3 lbs.
Bracket 1.3 lbs.
Compliance: Power Adapter CE, C-UL
PI30 Only
Wireless System
Receiver: One 16 channel selectable UHF diversity wireless receivers 798-805 MHz.
Antennas are hidden internally.
Microphone Transmitters: Handheld wireless microphone or beltpack transmitters
optional. Powered by 2 ea. 1.5 volt AA batteries (included). Choice of headset,
collar or lapel microphone for the beltpack.
PI30 and PI30-PS
Line In Line level RCA jacks (2) providing for audio input from CD, Tuner,
LCD projector via cable.
Mic. In 1/4” jack for microphones with a cable.
