Great Planes Sukhoi SU-31 ARF - GPMA1185 - Manual (Page 5)

5
1
2 2
13
3
9
12 11
10
6
7
8
5
4
Before starting to build, use the Kit Contents list to take an inventory of this kit to make sure it is complete and inspect
the parts to make sure they are of acceptable quality. If any parts are missing or are not of acceptable quality, or if you
need assistance with assembly, contact Great Planes Product Support. When reporting defective or missing parts, use
the part names exactly as they are written in the Kit Contents list on this page.
3002 N. Apollo Drive, Suite 1, Champaign, IL 61822
Telephone: (217) 398-8970, Fax: (217) 398-7721
E-mail: [email protected]
KIT CONTENTS
1 Wing
2 Ailerons (2)
3 Fuselage
4 Stab w/elevators
5 Rudder w/wood post
6 Vertical fin
7 Stab braces 8 Stab slot filler
9 Hook & loop mounting strips
10 Aileron hinge strips
11 Plastic tie-wraps
12 Landing gear wire
13 Wheels
Kit Contents (Photographed)
(2) Aileron pushrod
(2) Plastic wheel collars
Elevator pushrod
(4) Control horn Rudder pushrod
Wire tail-skid
(4) Screw-lock connector, screw, retainer
Kit Contents (Not Photographed)
