3. With the servos centered, install a servo arm onto each
servo. Trim the arms as shown.
❏
4. Locate the two 40" [1016 mm] pushrod wires. Put a
Z-bend in one end of each wire as shown. Z-bend pliers
work best for this.
❏
5. Insert each wire into the pushrod guide tubes in
the fuselage.
❏
6. Remove the servo arms and insert the Z-bend into the
second hole out from center on the arms. Reattach the
servo arms and servo arm screws.
❏
7. Position a white nylon control horn in line with the
rudder pushrod exiting the fuselage. The control horn should
be 1/2" [13 mm] from the top of the stab as shown. Ensure
the holes in the control horn line up with the hinge line. Mark
the location of the control horn screws with a felt-tip pen or
pencil. Drill 3/32" [2.4 mm] holes at these marks. Attach the
control horn to the elevator control surface using two of the
supplied #2 x 1/2" [13 mm] machine screws and a white
backplate on the back of the control surface.
9
