7. Locate one 14" [356mm] bent aileron pushrod wire.
Slide the wire into the pushrod guide tube located near the
control horn as shown.
❏ ❏
8. Insert the bent end of the pushrod into the middle
hole on the control horn. Attach a black nylon control horn
keeper to the pushrod as shown. Secure the snap keeper
to the pushrod with a drop of thin foam safe CA.
❏
9. Repeat steps 4 through 8 for the other side of the wing.
❏
10. Locate one of the pushrod quick connectors. Remove
the servo arm and attach the quick connector as shown. Use
a sharp hobby knife to enlarge the hole in the arm to allow the
connector to rotate freely. Add a drop of Threadlocker to the
bottom screw to prevent it from backing out.
❏
11. Slide both aileron pushrods through the hole in the
quick connect as shown and reattach the servo arm.
❏
12. Center both ailerons and then tighten the set screw on
the quick connector to secure the aileron pushrods.
