Before starting to build, use the Kit Contents list to take an inventory of this kit to make sure it is complete and inspect
the parts to make sure they are of acceptable quality. If any parts are missing or are not of acceptable quality, or if you
need assistance with assembly, contact Great Planes Product Support. When reporting defective or missing parts, use
the part names exactly as they are written in the Kit Contents list on this page.

3002 N. Apollo Drive, Suite 1, Champaign, IL 61822

Telephone: (217) 398-8970, Fax: (217) 398-7721

E-mail: [email protected]

KIT INSPECTION

1. Fiberglass Fuselage
2. Right Wing Panel w/Aileron
3. Left Wing Panel w/Aileron
4. Horizontal Stabilizer w/Elevators
5. Rudder
6. Wing Center Section
7. Center Section Bottom Fairing

8. Cowl Top [2]
9. Cowl Bottom [2]

10. Cowl Front [2]
11. Propellers [2]
12. Propeller Adapters [2]
13. Speed 400 Motors [2]
14. Wiring Harness w/ ESC and Switch

15. 1/8" [3.2mm] Ply Servo Tray
16. 51.5mm Main Wheels [2]
17. 1/8" [3.2mm] Ply Mid Former (Servo Tray)
18. 1/8" [3.2mm] Ply Aft Former (Servo Tray)
19. 1/8" [3.2mm] Ply Wing Joiners [4]
20. Fiberglass Nose Hatch Strips [4]
21. 1/8" [3.2mm] Ply Forward Battery Tray

Kit Contents (Photographed)

5mm x 50mm Wooden Dowel
Velcro

Battery Straps [2]

2.0mm Elevator Joiner
1.7x99mm Aileron Pushrods [2]
2.5mm Washers (Motor Mount) [4]
2.5x11.5mm Flanged Phillips Screws

(Landing Gear Straps) [4]

2.5x7.5mm Phillips Screws (Motor

Mounts) [4]

Nylon Tie Strap
2.5x9.5mm Flanged Phillips Screws [6]
25mm Tail Wheel

75mm Main Landing Gear [4]
Decal
2mm Wheel Collar (Tailgear)
2x12mm Phillips Screws (Rudder/Elevator) [4]
2x16mm Phillips Screws (Ailerons) [4]
3mm Set Screws [18]
3x34mm Axles [2]
4mm Washers (Wing Bolts) [2]
4x22mm Wing Bolt [2]
600mm Pushrod Outer Tubes [2]
700mm Pushrods w/Z-Bends [2]
Propeller Shaft Extensions [2]

CA Hinges [4]
Hinge Points [2]
Wing Bolt Blind Nuts (Installed in Fuse)[2]
Large Nylon Clevis [2] w/Retainers
Main LG Adapters [4]
Nylon LG Straps [2]
Plastic Spacers for Landing Gear [4]
Screw-Lock Connectors
Nylon Retainers (Screw-Lock Connectors) (2)
Small Nylon Control Horns [4]
Tailgear Wire
