Page 15

“HOOK” SIDE

“LOOP” SIDE

❏

3. To mount your battery with a strap, ﬁ rst apply the

rougher, “hook” side of the included adhesive-backed Velcro
material to the plywood external battery plate and the
softer, “loop” side to your battery. Mount your battery to the
plate. Then make a strap from the included non-adhesive

Velcro strips.

❏

4. Glue the strap across the bottom of the battery plate

with CA.

❏

5. Sand a small bevel to the front of the top of the external

battery plate.

❏

6. Using care not to drill down through the bottom of the

fuselage, enlarge the hole in the battery plate in the fuselage
with a 3/32" [2.4mm] drill. Cut the “window” from the battery
plate to accommodate the Velcro strap.

❏

7. Insert the battery plate with the battery into the fuselage

making sure the tab in the front locks into the notch in the
former. Secure the battery plate with the included 3mm
Phillips wood screw.
