Page 2
2
- P a r t s L i s t -
Item Qty p/n
Description
1 12
101048
Slide
Block
2 6
101069
Canopy
Pole
3
8
101080
1/4" Dia. X 1-1/4" Long Phillips Screw
4 8
101081
1/4"
Flat
Washer
5
40
101082
1/4" Thin Locknut
6 8
101083
Tube
Cap
Spacer
7
6
101088
1/4" Dia. X 3/4" Long Phillips Screw
8 1
101095
Tow
Rope
9 1
101116
U-Channel
Molding
10
2
101121
Porch Pole
11
1
101124
Short Roof Spreader Pole
12
1
101130
Long Roof Spreader Pole
13
6
101146
1-1/2" X 1-3/4" Aluminum Angle X 9" Long
14
12
101147
#10 X 1" Long Phillips Screw
15
16
101148
#6 X 3/8" Long Phillips Screw
16
2
101167
Front Adjustable Spreader Pole
17 3
101399
Seat
Swivel
Assembly
18 3
101420
Front
Seat
Bracket
19
3
101424
Rear Seat Bracket
20
12
101429
1-1/8" Dia. Tube Cap
21
2
101430
1" x 2" Rectangular Tube Cap
22
1
101438
1" X 2" Rectangular Support Tube
23 3
101442
Latch
Clip
24 3
101466
Cloth
Accessory
Hammock
25
23
101470
1/4" Dia. X 1/2" Long Hex Head Screw
26
1
101479
Porch Hoop Pole
27 3
101482
Canopy
Hoop
Pole
28
12
101486
1/4" Dia. X 1-3/4" Long Phillips Screw
29
2
101487
1/4" Dia. X 2-3/4" Long Phillips Screw
30
2
101580
Rear Adjustable Spreader Pole
31
1
101584
Left Canopy Bracket
32 1
101585
Right
Canopy
Bracket
33 1
101626
Voyager
Base
34
6
101652
1-1/8" Dia. Tube
35 3
101898
Folding
Seat
Assembly
36 1
102131
Voyager
Tent
