PA G E 4 I N S T R U C T I O N M A N UA L R C U 9 2 0 0
INSTALLATION
Mounting
The RCU9200 is designed to be panel
mounted . The mounting assembly
supports mounting into panels of up
to 10 mm thick . Before mounting, the
RCU9200 requires a hole of 76 mm to
be cut in the panel .
Using the supplied template (page 11)
mark the location of the hole to be cut .
Make sure there is at least 60 mm of
clearance behind the panel to allow
for the depth of the remote unit and
its cables . There should also be at least
another 10 mm clearance around the
hole for the front panel facia and the
U-Bracket mounting clamp .
Cut the 76 mm hole using a hole saw
or similar .
Mount the RCU9200 through the hole
from the front of the panel . Ensure
the rubber gasket is between the front
facia and the mounting surface .
Remove the two top nuts from the
two bolts on the rear of the unit . DO
NOT remove the two bottom nuts as
these are required to hold the bolts
in place .
Slide the U-bracket over the bolts
ensuring the clearance slots in the
bracket are positioned as shown .
Slide the bracket forward until it
presses against the rear of the
mounting surface .
Refit the two nuts and tighten . Do
NOT over tighten otherwise damage
to the rear of the RCU9200 case
may occur .
Wiring
Connect the attached fly lead to one of
the two in-line connectors at the rear
of the GR9200/GD9600 If required
the cable can be extended using
one or more optional LE024 5 meter
extension leads (up to a maximum of
15 meters) .
The single terminal pin on the rear of
the case is used to activate the back
lighting for the RCU9200 display
and keypad . Connect this to a +12
V DC source using an insulated
spade connector (to prevent the
terminal shorting to the U-bracket) .
Connecting this to an accessory point
in your vessel will ensure the back
lighting turns on and off with your
vessels accessory switch .
