S6+ mounting template, Outer edge of grill speaker hole – GME GS650 User Manual

Page 5

background image

S6+ Mounting Template

3.3 mm

drill bit

145 mm

diameter

188 mm

diameter

6.8 mm

DN - 46857-1 PN - 310588

Outer

edge of grill

Speaker

hole
