Capacities and Specifications
Please refer to Recommended Fluids and Lubricants on page 6-12. All capacities are approximate. When adding, be
sure to fill to the appropriate level or as recommended in this manual.
See refrigerant charge label under the hood for charge capacity information and requirements.
Model Description Torque
G/H 1500 6 Bolts (14 mm) 140 lb ft (190 Y )
G/H 2500 & G/H 3500 8 bolts (14 mm) 140 lb ft (190 Y )
Tire Pressure
See the “Certification/Tire Label” under Loading Your Vehicle
on page 4-31 This label is located on the rear edge of the
driver’s door.
Application
Capacities
QTY Without Rear
Heater QTY With Rear Heater
Cooling System
After refill, the level must be rechecked. See “Cooling System” in the Index.
VORTEC™ 4300 V6 11.0 quarts (10.4 L) 14.0 quarts (13.2 L)
VORTEC™ 4800 V8 13.4 quarts (12.7 L) 16.4 quarts (15.5 L)
5-106
