Black plate (40,1) GMC Savana Owner Manual - 2011
10-40 Vehicle Care
Headlamps
A. High‐Beam Headlamp
B. Low‐Beam Headlamp
To remove the headlamp assembly
from the vehicle and access the
bulbs:
1. Open the hood. See Hood on
page 10‑6 for more information.
2. Remove the two bolts from the
headlamp assembly.
3. Lift the headlamp assembly to
release the lower tabs from the
radiator support.
4. Turn the headlamp forward and
upward to remove it from the
grille.
5. Disconnect the electrical
connector.
6. Turn the bulb counterclockwise
one quarter turn to remove it
from the headlamp assembly.
7. Install the new bulb into the
headlamp assembly and connect
the electrical connector.
