DMX Channel Values (13 Channel)
C
HANNEL
V
ALUE
F
UNCTION
1
000 Ù 255
Pan
2
000 Ù 255
Pan Fine
3
000 Ù 255
Tilt
4
000 Ù 255
Tilt Fine
5
000 Ù 255 Vector Speed: (Normal → Slow)
6
000 Щ 007
008 Щ 134
135 Щ 239
240 Щ 255
Dimmer/Strobe
Closed
100-0%
Strobe (slow → fast)
Open
7
000 Ù 255
Red
0-100%
8
000 Ù 255
Green
0-100%
9
000 Ù 255
Blue
0-100%
10
000 Щ 007
008 Щ 018
019 Щ 031
032 Щ 043
044 Щ 055
056 Щ 067
068 Щ 079
080 Щ 091
092 Щ 103
104 Щ 115
116 Щ 127
128 Щ 139
140 Щ 151
152 Щ 163
164 Щ 175
176 Щ 187
188 Щ 199
200 Щ 212
213 Щ 225
226 Щ 239
240 Щ 255
Color Macros
No Function
Magenta
Purple
Orange
Pink
Yellow
Pale Green
Light Blue
Teal
Sky Blue
Blue
Olive
Turquoise
Orange
Yellow
Magenta
White
Color-Change Macro 1
Color-Change Macro 2
Color-Change Macro 3
Color-Change Macro 4
11
000 Ù 255 Vector Speed (Color)
12
000 Щ 007
008 Щ 022
023 Щ 037
038 Щ 052
053 Щ 067
068 Щ 082
083 Щ 097
098 Щ 112
113 Щ 127
128 Щ 142
143 Щ 157
158 Щ 172
173 Щ 187
188 Щ 202
203 Щ 217
218 Щ 232
233 Щ 255
Movement Macros
No Function
Auto Program 1
Auto Program 2
Auto Program 3
Auto Program 4
Auto Program 5
Auto Program 6
Auto Program 7
Auto Program 8
Sound Active1
Sound Active 2
Sound Active 3
Sound Active 4
Sound Active 5
Sound Active 6
Sound Active 7
Sound Active 8
13
000 Ù 255
Reserved
