Futaba 8UHFS, 8UHPS - Manual (Page 34)

30
Setting the Failsafe Function
Channel
display
"NORM" or
Failsafe position
(NORM shown)
*The blinking item is what is
being set.
Channel display
No.
CH1
CH2
CH3
CH4
Channel Name
AI = Aileron
EL = Elevator
TH = Throttle, AB: Air brake
RU = Rudder
No.
CH5
CH6
CH7
CH8
Channel Name
GE = Landing gear, GY = Gyro, 5 = Channel 5
FL = Flap, PI = Pitch
Channel 7
Channel 8
To REVERS
function
To IDL-DN
function Data input keys
These keys are used to set
failsafe for channels 1-8 in
this menu.
1. Aileron fail safe setting
Select the Failsafe function
for CH1 by pressing the (-)
key. Next, hold the aileron
stick in the position you want
to memorize and set the
position by pressing the (+)
and (-) keys simultaneously.
(If you wish, you may return
to the NORM position by
pressing the (+) key )
2. Set the following
channels in the same
manner: CH2 = Elevator,
CH3 = Throttle, CH4 =
Rudder, CH5 = Landing
gear, CH6 = Flap, CH7, CH8
The initial setting for all channels
is "NORM". When failsafe mode
is turned on, the initial position
settings are 50% for throttle and
0% for the other channels.
When you choose the failsafe mode, check that your settings are correct by turning off the transmitter
power switch and verifying that the servos move to the settings that you chose. Be sure to wait at
least one minute after turning on the transmitter and receiver power before turning off the transmitter.
The servo reverse function may be used when you need to change the direction that a
servo responds to a control stick motion. When you use this function, BE SURE
THAT YOUR CONTROL IS MOVING THE CORRECT DIRECTION. If you are
using Advance Menu functions, set correct travels in the REVERS menu first, before
setting up the Advance Menu.
Reversing Servos
To PARA
function
To F/S function Data input keys
These keys are used to
reverse channels 1-8 in
this menu as needed.
Channel display NORM or REV
display indicates
travel setting
1. Aileron setting
Select "NORM" or "REV" with the
(+)/(-) keys.
2. Repeat above procedure to reverse
channels 2-8 as necessary:
2 = Elevator
3 = Throttle
4 = Rudder
5 = Landing gear
6 = Flap
7 = CH7
8 = CH8
Indicates NORM or REVERS throw
setting
*The blinking item is what is
being set.
