2peka, Assembly / adjustment, Receiver and servo connection – Futaba 2PEKA User Manual
Page 11: 9assembly / adjustment, Gas powered model
9
Assembly / Adjustment
Assembly / Adjustment
Receiver and Servo Connection
As you connect the receiver, servo's and other components, do so in accordance with the
"Assembly Precautions" listed on the next page.
2PEKA
Connections when a E.S.C. MC210CB or MC310CB are used.
Gas Powered Model
Steering Servo
Throttle Servo
Receiver
Receiver
E.S.C.
Power Switch
To Receiver
Battery
Power Switch
Connects to Motor
Connects to battery
(CH1)
(CH2)
(CH1)
(BATT)
(CH2)
ON
OFF
Steering Servo
