Fredenstein Bento 6 Module Carrier
Specifications:
Input Voltage: 90V AC to 240V AC, 50 to 60 Hz
Output Voltages: +16V DC 1.6A
-16V DC 1.6A
+48V DC 0.3A
Power Consumption: max 90W
Dimension (LxHxD): 300mm x 135mm x 190mm (without handle and feet)
350mm x 145mm x 190mm (including handle and feet)
Weight: 3.8kg(NW) ; 4.8kg(GW)
Fredenstein Bento 6 Module Connector Pin Description
Solder Side
Pin Number Signal
Pin 1 Frame Ground
Pin 2 Main Out +
Pin 3 AUX Out +
Pin 4 Main Out -
Pin 5 Audio Ground
Pin 6 Compressor Buss
Pin 7 AUX Out -
Pin 8 Main In -
Pin 9 AUX In -
Pin 10 Main In +
Pin 11 AUX In +
Pin 12 +16V Supply
Pin 13 Supply Ground
Pin 14 -16V Supply
Pin 15 +48V Supply
Fredenstein Bento 6 Manual V1.1 July 18, 2014 Page 3
