Fredenstein F600A Compressor
The F600A Compressor is a high performance tool for professional recording and mastering
engineers. The F600A features a fully externally and internally balanced signal path with much
lower distortion than conventional compressors. It comprises of a analog gain control circuit and
and a digital side-chain based on two DSPs. This technology can achieve more than 20 dB of gain
reduction while maintaining very low distortion. Up to ten units can be linked together to form a
true multi-channel compressor. The engineer can easily change the compression characteristics by
tuning threshold level, attack and release times as well as selecting RMS or PEAK signal inputs to
the side-chain. An additional tunable high pass filter preserves low frequencies. Since this high pass
filter can be tuned up to 4 kHz, the F600A can be used as De-Esser, or on a lathe, as a cutting speed
limiter. The extreme low output impedance with its high current design allows even the most
difficult and complex loads to be driven without sonic impact. As all Fredenstein products, the
F600A is designed by a German-American team and manufactured in Taiwan.
Overview:
Gain Reduction Indicator
(not active in Bypass Mode)
Rotary Controls:
GAIN : Make-up Gain Control
THR : Threshold Control
ATT : Attack Time Control
REL : Release Time Control
HPF : Side-chain Low-Cut Filter
CR : Compression Ratio
Switches:
ON : if lit the compressor is active, if not a
hard bypass is switched on
PEAK-RMS : Side-chain input RMS or Peak and
selects Hard- or Soft-Knee mode
LINK : Enables Multi-Channel Link capability
Fredenstein F600A Manual V1.2 July 18, 2014 Page 1
