Fredenstein F605 Headphone Amplifier
The F605 is a high performance professional headphone amplifier, offering an effective headphone
volume control for live or studio applications out of a Fredenstein Bento rack. The F605 features
balanced inputs, extended signal manipulation and a low output impedance to connect headphones
from 20 Ohms to 600 Ohms.
As all Fredenstein products, the F605 is designed by a German-American team and manufactured in
Taiwan.
Overview:
LED Indicators:
PWR : A green LED indicates presence of power
CLIP : A red CLIP indicator turns on at 2db below
clipping output level
Rotary Controls:
Volume : Volume control
Switches:
L<->R : flips the channels, left on right ear, right on left
ear
L CH : Both sides are reproducing the left channel only
R CH : Both sides are reproducing the right channel
only
if L CH and R CH are activated a mono signal is
reproduced on both sides
L POL : Selects the phase of the left channel
R POL : Selects the phase of the right channel
Connector:
Headphones : Unbalanced Stereo headphone output (TRS)
Fredenstein F605 Manual V1.1 July 18, 2014 Page 1
