FloAire FKB-INLINE - Manual (Page 13)

13
Pulley Combination Chart for 1800 RPM Motors
Motor RPM 1725
1/3 to 2 HP MOTOR PULLEY Dd1 Dd2 Pd1 Pd2
AX BELTS 1VL40 2.4 3.4 2.6 3.6
Open C losed
BLOWER PULLEY DATUM DIAMETER PITC H DIAMETER 5 4 1/2 4 3 1/2 3 2 1/2 2 1 1/2 1 1/2 0
AK114 11 11.2 400 416 431 447 462 477 493 508 524 539 554
AK94 9 9.2 488 506 525 544 563 581 600 619 638 656 675
AK79 7.5 7.7 582 605 627 650 672 694 717 739 762 784 806
AK66 6.2 6.4 701 728 755 782 809 836 863 889 916 943 970
AK54 5 5.2 863 896 929 962 995 1028 1062 1095 1128 1161 1194
AK46 4.2 4.4 1019 1059 1098 1137 1176 1215 1255 1294 1333 1372 1411
AK39 3.5 3.7 1212 1259 1305 1352 1399 1445 1492 1539 1585 1632 1678
AK32 3 3.2 1402 1455 1509 1563 1617 1671 1725 1779 1833 1887 1941
1/3 to 2 HP MOTOR PULLEY Dd1 Dd2 Pd1 Pd2
AX BELTS 1VP50 3.4 4.4 3.6 4.6
BLOWER PULLEY DATUM DIAMETER PITC H DIAMETER 5 4 1/2 4 3 1/2 3 2 1/2 2 1 1/2 1 1/2 0
AK32H 3 3.2 1941 1995 2048 2102 2156 2210 2264 2318 2372 2426 2480
3 to 5 HP MOTOR PULLEY Dd1 Dd2 Pd1 Pd2
BX BELTS 2VP42 2.9 3.9 3 4
Open
BLOWER PULLEY DATUM DIAMETER PITC H DIAMETER 6 5 1/2 5 4 1/2 4 3 1/2 3 2 1/2 2 1 1/2 1 1/2
2BK160H 15.4 15.7 330 339 348 357 366 375 385 394 403 412 421 430
2BK140H 13.4 13.7 378 388 399 409 420 430 441 451 462 472 483 493
2BK120H 11.4 11.7 442 455 467 479 491 504 516 528 541 553 565 577
2BK110H 10.4 10.7 484 497 511 524 537 551 564 578 591 605 618 631
2BK100H 9.4 9.7 534 548 563 578 593 608 622 637 652 667 682 697
2BK90H 8.4 8.7 595 611 628 644 661 677 694 710 727 744 760 777
2BK80H 7.4 7.7 672 691 709 728 747 765 784 803 821 840 859 877
2BK70H 6.4 6.7 772 794 815 837 858 880 901 923 944 965 987 1008
2BK60H 5.4 5.7 908 933 958 984 1009 1034 1059 1084 1110 1135 1160 1185
2BK55H 4.9 5.2 995 1023 1050 1078 1106 1133 1161 1189 1216 1244 1272 1299
2BK50H 4.4 4.7 1101 1132 1162 1193 1223 1254 1285 1315 1346 1376 1407 1438
2BK45H 3.9 4.2 1232 1266 1301 1335 1369 1403 1438 1472 1506 1540 1574 1609
2BK40H 3.6 3.9 1327 1364 1401 1438 1474 1511 1548 1585 1622 1659 1696 1732
2BK36H 3.4 3.7 1399 1438 1476 1515 1554 1593 1632 1671 1709 1748 1787 1826
7-1/2 to 10 HP MOTOR PULLEY Dd1 Dd2 Pd1 Pd2
BX BELTS 2VP60 4.3 5.5 4.7 5.9
Open
BLOWER PULLEY DATUM DIAMETER PITC H DIAMETER 6 5 1/2 5 4 1/2 4 3 1/2 3 2 1/2 2 1 1/2 1 1/2
2BK160H 15.4 15.7 516 527 538 549 560 571 582 593 604 615 626 637
2BK140H 13.4 13.7 592 604 617 630 642 655 667 680 693 705 718 730
2BK120H 11.4 11.7 693 708 722 737 752 767 781 796 811 826 840 855
2BK110H 10.4 10.7 758 774 790 806 822 838 854 871 887 903 919 935
2BK100H 9.4 9.7 836 854 871 889 907 925 943 960 978 996 1014 1031
2BK90H 8.4 8.7 932 952 972 991 1011 1031 1051 1071 1091 1110 1130 1150
2BK80H 7.4 7.7 1053 1075 1098 1120 1143 1165 1187 1210 1232 1255 1277 1299
2BK70H 6.4 6.7 1210 1236 1262 1287 1313 1339 1365 1390 1416 1442 1468 1493
2BK60H 5.4 5.7 1422 1453 1483 1513 1543 1574 1604 1634 1664 1695 1725 1755
2BK55H 4.9 5.2 1559 1592 1625 1659 1692 1725 1758 1791 1825 1858 1891 1924
3 to 5 HP MOTOR PULLEY Dd1 Dd2 Pd1 Pd2
BX BELTS 2VP42 2.9 3.9 3 4
Open
BLOWER PULLEY DATUM DIAMETER PITC H DIAMETER 6 5 1/2 5 4 1/2 4 3 1/2 3 2 1/2 2 1 1/2 1 1/2
2B5V278 27.8 28.1 379 390 400 411 421 432 442 453 463 474 484 495
2B5V250 25 25.3 421 433 444 456 468 479 491 503 514 526 538 550
2B5V234 23.4 23.7 449 462 474 487 499 512 524 537 549 562 574 587
2B5V200 20 20.3 525 539 554 568 583 597 612 627 641 656 670 685
2B5V184 18.4 18.7 570 585 601 617 633 649 664 680 696 712 728 744
2B5V160 16 16.3 653 672 690 708 726 744 762 780 799 817 835 853
2B5V154 15.4 15.7 678 697 716 735 754 773 791 810 829 848 867 886
2B5V136 12.6 12.9 826 849 871 894 917 940 963 986 1009 1032 1055 1078
2B5V124 12.4 12.7 839 862 885 908 932 955 978 1002 1025 1048 1072 1095
2B5V110 11 11.3 942 969 995 1021 1047 1073 1100 1126 1152 1178 1204 1230
7-1/2 to 10 HP MOTOR PULLEY Dd1 Dd2 Pd1 Pd2
BX BELTS 2VP60 4.3 5.5 4.7 5.9
Open
BLOWER PULLEY DATUM DIAMETER PITC H DIAMETER 6 5 1/2 5 4 1/2 4 3 1/2 3 2 1/2 2 1 1/2 1 1/2
2B5V278 27.8 28.1 594 606 619 632 644 657 670 682 695 707 720 733
2B5V250 25 25.3 659 674 688 702 716 730 744 758 772 786 800 814
2B5V234 23.4 23.7 704 719 734 749 764 779 794 809 824 839 854 869
2B5V200 20 20.3 822 839 857 874 892 909 927 944 962 979 997 1014
2B5V184 18.4 18.7 892 911 930 949 968 987 1006 1025 1044 1063 1082 1101
2B5V160 16 16.3 1024 1045 1067 1089 1111 1133 1154 1176 1198 1220 1241 1263
2B5V154 15.4 15.7 1063 1085 1108 1131 1153 1176 1198 1221 1244 1266 1289 1311
2B5V136 12.6 12.9 1293 1321 1348 1376 1403 1431 1459 1486 1514 1541 1569 1596
2B5V124 12.4 12.7 1314 1342 1370 1398 1426 1454 1481 1509 1537 1565 1593 1621
2B5V110 11 11.3 1477 1508 1539 1571 1602 1634 1665 1696 1728 1759 1791 1822
15 to 20 HP MOTOR PULLEY Dd1 Dd2 Pd1 Pd2
BX BELTS 2VP75 5.8 7 6.2 7.4
Open
BLOWER PULLEY DATUM DIAMETER PITC H DIAMETER 6 5 1/2 5 4 1/2 4 3 1/2 3 2 1/2 2 1 1/2 1 1/2
2B5V278 27.8 28.1 381 387 393 399 405 411 417 424 430 436 442 448
2B5V250 25 25.3 423 430 436 443 450 457 464 470 477 484 491 498
2B5V234 23.4 23.7 451 459 466 473 480 488 495 502 509 517 524 531
2B5V200 20 20.3 527 535 544 552 561 569 578 586 595 603 612 620
2B5V184 18.4 18.7 572 581 590 600 609 618 627 636 646 655 664 673
2B5V160 16 16.3 656 667 677 688 698 709 720 730 741 751 762 773
2B5V154 15.4 15.7 681 692 703 714 725 736 747 758 769 780 791 802
2B5V136 12.6 12.9 829 842 856 869 883 896 909 923 936 949 963 976
2B5V124 12.4 12.7 842 856 869 883 896 910 924 937 951 964 978 992
2B5V110 11 11.3 946 962 977 992 1008 1023 1038 1053 1069 1084 1099 1114
** 2HP Motors on 20 IN Blowers use 2VP42 Pulleys
1
0
-
2
0
I
N
.
B
L
O
W
E
R
*
*
2
5
I
N
.
B
L
O
W
E
R
TURNS ON MOTOR PULLEY
TURNS ON MOTOR PULLEY
TURNS ON MOTOR PULLEY
TURNS ON MOTOR PULLEY
TURNS ON MOTOR PULLEY
TURNS ON MOTOR PULLEY
