EN 10
FDV 1002-A
Putting into operation
5. As soon as the battery is fully charged, the green indicator light will stay on and the red indicator light will
turn off.
6. After fully charging, disconnect the charger from the power socket. Before fi rst use the battery must be fully
charged.
For the fi rst charge, it is recommended to charge the batter for 3 -5 hours.
Drill chuck (see pic. 3)
If you wish to open up the drill chuck, hold the rear part of the chuck and turn the front part of the chuck
anticlockwise. Insert the desired tool into the chuck. When tightening turn the front part of the chuck (while
holding the rear part) clockwise and ensure that the jaws of the chuck fi rmly and evenly clamp the working tool.
Torque control (see pic. 4)
1. Torque control is ideal for presetting screwing strength. There are 19 positions + 1 drilling position. These
positions are selected by turning the setting ring. Low values are intended for small screws and soft
materials. High values are intended for large screws and hard materials.
2. If the torque control is used the clutch will work in the preset setting. This is ideal for repeat screwing, when
all screws need to be screwed in at the same distance.
3. It is appropriate to start with the lowest setting and increase the amount of torque until the desired setting is
achieved.
Turning on/off (see pic. 5)
ATTENTION: Start or release the start switch carefully according to the manufacturer's instructions.
Turn on the charged machine using the trigger switch (no. 1). The On indicator will appear on the LED display.
Turn off the machine by releasing the switch, the chuck will stop turning.
1. Ensure that a battery is connected to the tool.
2. Start the tool by pressing the trigger switch.
3. The pressure applied to the power trigger switch determines the operating rotation speed of the chuck. The
higher the pressure exerted on the trigger switch, the higher the rotation speed of the chuck.
4. If you want the chuck to rotate forwards, push the forward/back direction switch (no. 2) to the left. If you want
the chuck to rotate backwards, push the forward/back direction switch to the right..
5. If the drill is not being used, set the forward/back direction switch (no. 2) to the neutral position (in the
middle), to prevent accidentally starting the drill.
Ensure that the bit or extension piece is correctly seated.
The bit/extension piece must be placed directly on the workpiece before the drill is turned on. Otherwise the
workpiece or the bit/extension piece will be damaged.
Always check the rotation direction of the bit before using.
The braking system is activated automatically after the trigger switch is released. The drill chuck will
automatically stop rotating.
