USER‘S MANUAL HIGH-PRESSURE WASHER
EN Troubleshooting guide
Connecting and
Disconnecting the
Spray Lance
Note: Due
to the high
pressures produced
by your pressure
washer, the lance
must seal lightly
to the gun. As the
result of normal
operation the
lance can become
difficult to attach
or remove and this
process may require
considerable force.
To attach the Lance - apply steady
downward pressure on the lance (in the
direction of the trigger) while simultaneously
twisting the lance 90° counter clockwise. It
may help if you set the gun vertically on a flat
surface with the lance pointing upwards. The
two tabs on the end of the lance must be fully
inserted in the gun before the lance will twist
and lock. If this does not work then remove the
bayonet o-ring from the end of the lance and
attach the lance to the gun without the o-ring in
place. You will need to replace the o-ring.
To remove the Lance - release any
trapped pressure in the gun f hose by turning
the unit OFF and squeezing the gun trigger.
Apply steady downward pressure on the
lance (in the direction of the trigger) while
simultaneously twisting the lance 90°
clockwise. It may help if you set the gun
vertically on a flat surface with the lance
pointing upwards.
