FDW 2002 E
22 EN Technical specifications
9. TEChNICAL SPECIFICATIONS
Nominal voltage 230 V
Nominal frequency 50 Hz
Nominal power input 1500 W
Nominal pressure 8 MPa
Maximum pressure 12 Mpa
Nominal flow rate 5,7 L/ min.
Maximum flow rate 8 L/ min.
Maximum feed water temperature 40°C
Hose length 5 m
Operating range 10 m
Internal protectio II.
Power cord length 5 m
Dimensions (width x depth x height) 285 x 360 x 740 mm
Weight without accessories 7,6 kg
Weight with accessories 8,9 kg
Maximum water inlet pressure in pascals 0,68 MPa
Minimum water inlet pressure in pascals in
case it is necessary for correct operation of
appliance
0,05 MPa
Sound pressure level (Lpa) 92 dB
Sound power level, measured (Lwa 96 dB
The appliance shall be connected to the power supply systems of the Z max impedance in
the place of connection (a household connection) up to 0.0277 ohms. The user shall be
responsible for connecting the appliance to the power supply networks which complies with the
above mentioned requirement. You can inform about the system impedance at the local power
distributor´s office, if necessary.
Changes of the text and technical specifications reserved.
The User’s Manual is in a specific language version.
