3. MACHINE DESCRIPTION
AND INCLUDED CONTENTS
MACHINE DESCRIPTION (see pic. 1)
1 Handle 7 Height adjust handle
2 Brake lever 8 Air filter
3 Driver lever 9 Side discharge board
4 Startér 10 Side discharge switch
5 Quick fix handle 11 Spark plug
6 Grass catcher
ƽ
WARNING: Sharp blades.
Supplied contents
Carefully take out the lawnmower from the packaging and check whether all the following parts are present:
Self-propelled lawnmower 1 piece
Grass catcher 1 piece
Bearing 4 pieces
Wheels 2 pieces
Wheel center 2 pieces
Nuts 2 pieces
Washer 2 pieces
User’s manual
If there are parts missing or they are damaged, please contact the retailer from whom you bought the machine.
