FZV 4001 E
12 EN Symbols | Machine description and package content
3. MACHINE DESCRIPTION AND
PACKAGE CONTENT
Machine description (see Fig.1)
1 - switch lever
2 - handle top
3 - handle bottom
4 - grassbox
5 - handle mounting nut
6 - discharge chute cover
7 - height of cut adjusting lever
Always switch off the engine and
remove the plug from mains before
performing any adjustment or
maintenance of the machine or if the
power supply cable is entangled or
damaged.
Use protective equipment while
working.
Before performing any work on the
mower, remove the cable from the
mains.
