ELECTRIC STRING TRIMMER
USER'S MANUAL
8
Assembly of the machine | Putting into operation
Replacing the spool with line
ATTENTION: Disconnect the string trimmer from the power source before replacing the spool.
Turn the bottom side of the head of the string trimmer towards yourself.
Press the clip on the line spool cover as shown on pic. 9 and remove the spool cover.
Take the spool out and remove the remains of the line found on the spool.
Thread the end of the line through the hole in the spool as shown in pic. 10. Check that the spring
is in its place under the spool. Pull the line through the opening on the machine's head so that the
line is tensioned when the spool is seated.
Note: Inside the head there is a spring that can easily be lost. Make sure that it is kept in a safe place.
Press the spool GENTLY downwards on to the spring and turn it until you feel that it has been
properly seated. Make sure that the line does not get stuck under the spool.
Reattach the spool cover, hold the string trimmer in the cutting position and turn on the machine.
Within a few second or even sooner you will hear how the line is cut off to the correct length. If the
line is not cut off, tap the butt on the butt lightly against the ground, which will release and extend
the length of the line.
5. PUTTING INTO OPERATION
Turning on the machine
The power plug located on the machine (pic. 1, no. 13) must be connected to an extension cord (not
included), secured by the pull reduction (no. 12)
Connecting to a power source
ATTENTION: Before connecting to a power source, always check that the switch is turned off.
Connect the power plug to the power source with current protection.
Putting into operation
Note: Before starting the string trimmer check the length of the nylon lines.
Hold the handle of the machine and with the thumb press the safety lock wheel of the trigger switch
(pid. 11, A) and then press the trigger switch (B). Turn off the string trimmer by releasing the trigger switch.
ATTENTION: Press or release the start switch carefully according to the manufacturer's
instructions.
ATTENTION: Make sure that feet are at a suffi cient distance from the trimming mechanism.
The nylon line will continue to slow down for a few seconds after the string trimmer is turned off. Wait
until the motor and the line are still before turning on the string trimmer again. Do not switch the string
trimmer on and off in short succession.
