Fawcett 105 Series Powerhead - Manual (Page 9)

REF. # 105NEMA PART # DESCRIPTION QTY.
1 AC988 DRIVE END CAP 1
*2 AB936 SHAFT SEAL 1
*3 AC989 O-RING 1
*4 AB927 DRIVE END BEARING 1
5 AB162 DOWEL PIN 4
6 AC965 DRIVE END PLATE 1
*7 AC888-B BODY GASKET 2
8 AC878C BODY 1
9 AB136D KEY 1
10 AC986 ROTOR ASSEMBLY 1
*11 AC879 PUSH PIN 2
*12 AC817 SPRING, VANE 4
*13 AC816 VANE 4
14 AC964 DEAD END PLATE 1
*15 AC894B DEAD END BEARING 1
*16 AC837 END CAP GASKET 1
17 AC836 DEAD END CAP 1
M07 MUFFLER ASSEMBLY 1
K211 SERVICE KIT
* INCLUDED IN K211 SERVICE KIT
MOTOR PARTS BREAKDOWN
105NEMA POWERHEAD
