SAFETY INSTRUCTIONS
To avoid the risk of electrical shock, do not attempt to open the unit.
There are no user-serviceable parts inside. Do not attempt to service the
equipment yourself. In case of problems, please contact your local dealer
or distributor.
This unit should be connected to a grounded power outlet. If you use
extension cords and power distributors they should be grounded as well.
Verify that the specified operating voltage on the rear side matches the
local mains voltage. If these values do not match you will have to adjust
the loudspeaker setting appropriately and change the fuse type.
Use only the fuse types specified on the rear side of the unit. Never bypass
the fuse.
Make sure that no liquids wet the inside of the cabinet. Never spray, pour
or spill liquids directly onto the unit.
Do not use a wet cloth nor flammable or acid chemicals for cleaning.
Do not touch the diaphragms of the loudspeaker and do not obstruct the
bass reflex ports.
Make sure there is enough air flow behind the loudspeaker to maintain the
electronic components cool.
Do not expose this product to extreme temperatures.
The diaphragms build up a magnetic field around the loudspeaker.
High sound pressure levels can damage your hearing permanently! Avoid
standing close to loudspeakers producing high sound pressure levels.
TABLE OF CONTENTS
1. INTRODUCTION ............................................................................4
2. QUICK START .................................................................................5
2.1. First Steps .............................................................................................................................5
2.2. Speaker Connection .........................................................................................................5
2.3. Powering On .......................................................................................................................5
3. OPERATION ...................................................................................6
3.1. First Steps .............................................................................................................................6
3.2. The Grid ................................................................................................................................6
3.3. Operating Modes ..............................................................................................................7
3.4. Powering on/off: Standby Mode .................................................................................7
3.5. Volume Mode .....................................................................................................................8
3.6. Settings Menu ....................................................................................................................9
3.7. Filters .....................................................................................................................................9
3.8.
Low Filter ..............................................................................................................................9
3.9. High Filter.......................................................................................................................... 10
3.10. Low and High Filter Combinations .......................................................................... 11
3.11. Desk Filter ......................................................................................................................... 11
3.12. LED Mode .......................................................................................................................... 12
3.13. Saving Your Settings ..................................................................................................... 12
3.14. Power Switch ................................................................................................................... 12
3.15. DIP Switches ..................................................................................................................... 13
3.16. Mains Voltage Selector ................................................................................................. 13
3.17. Power Connector (IEC) ................................................................................................. 14
4. POSITIONING ..............................................................................14
4.1. Speaker Positioning + Rubber Feet ......................................................................... 14
4.2. Height and Distance ..................................................................................................... 15
4.3. Stereo Setup..................................................................................................................... 15
4.4. Stereo Setup + Subwoofer (2.1) ................................................................................ 16
4.5. Multichannel Setup (5.1) ............................................................................................. 16
4.6. Mixer/Workplace Reflections ..................................................................................... 17
4.7. Room Acoustics .............................................................................................................. 18
5. TECHNICAL SPECIFICATIONS .....................................................19
6. DECLARATION OF CONFORMITY ...............................................20
7. WARRANTY ..................................................................................21
!
!
!
!
!
