7
Coaxial Output - Digital Audio Output Connector
When MPEG audio or Dolby Digital audio is played, Dolby Digital bitstream or MPEG audio bitstream is
sent to the player’s digital audio output connector. When the player is connected to a Dolby or MPEG audio
decorder via this output socket, you can enjoy theater-quality audio in your home. An optical audio cable is
required when a Dolby Digital decoder or MPEG audio decoder is used. The mentioned cable is not included
with this product.
External Audio and Video Signal Input - HDMI, RCA, S-VIDEO,COMPONENT.
The player's AV function would enable users to view programs from external signal sources.
Four input modes are available for you to chose from, it ranks as below in regard to image definition: HDMI/
COMPONENT/S-VIDEO/RCA
Cable Connections
Amplifier equipped with a
DolbyPro Logic Surround
Coaxial Cable
IMPORTANT NOTICE - When work with external device,
Be sure to have all necessary connections properly done before connect the •
power supply.
Set the unit into the relative input/output mode to enable the signal pass. •
Refer to the manual of external sources as well. •
NOTE:
We supply one set of AV cable and one piece of power cord with this product.
The white/red plug of the AV cable is for the audio L/R connection and the yellow
plug for the video connection. The white/red plug of the AV cable can also be used
separately to input the audio signal in the S-video/Component connection.
The rest of cable needed for other neccessary connections are not included with this
product, please check with electronic store.
