OPERATING INSTRUCTIONS
SPEAKER CONNECTION
Connect each speaker to the corresponding speaker terminals on the back panel
of the main unit. Make sure that the left (black) speaker wire is connected to the
left (L) black speaker clip and the right (red) speaker wire is connected to the right
(red) speaker clip.
Right Speaker
Left Speaker
SPEAKERS
RED
BLACK
