Technical Data
Frequency Response: <10 Hz – 200 kHz (-0.5 dB)
THD+N @ +15 dBu, 20 Hz - 22 kHz:
Stereo Mode (Direct)
0.0039 %
Stereo Mode (Compressed) 0.009 %
M/S Mode (Direct) 0.014 %
M/S Mode (Compressed) 0.034 %
Noise Floor, 20 Hz - 20 kHz (A-weighted):
Stereo Mode (Direct)
-95.8 dBu
Stereo Mode (Compressed) -89.3 dBu
M/S Mode (Direct) -95.6 dBu
M/S Mode (Compressed) -92.3 dBu
Dynamic Range, 20 Hz - 22 kHz:
Stereo Mode
122 dB
M/S Mode 118 dB
Maximum Input Level:
Stereo Mode
+28 dBu
M/S Mode +23 dBu
Maximum Output Level:
Stereo Mode
+27 dBu
M/S Mode +23 dBu
Input Impedance:
10 kOhm
Output Impedance: 68 Ohm
Pin Assignment Input: 1. GND
2. Positive (transformer balanced)
3. Negative (transformer balanced)
Pin Assignment Output: 1. GND
2. Positive
3. With 68 Ohm to GND
Power Consumption: 100 W max
Fuse Type: 115 VAC 3 A Slo-Blo/230 VAC 1.5 A Slo-Blo
Dimensions (W x H x D): 483 mm x 133 mm (3 U) x 405 mm
19“ x 5.3“ (3 U) x 16“
Weight: 16.0 kg/35 lb
