Operation
-12- Q-Spot™ 160-LED User Manual Rev. 01b
Continued from previous page
Edit Custom 1) Go to Edit.
2) Select Step.
a) Select a step number (000~255).
b) Activate the new value.
3) Select Pan.
a) Select a pan position (000~255).
b) Activate the new value.
4) Select Tilt.
a) Select a tilt position (000~255).
b) Activate the new value.
5) Select Speed.
a) Select a movement (pan & tilt) speed (000~255).
b) Activate the new value.
6) Select Color.
a) Select a color from the color wheel (000~255).
b) Activate the new value.
7) Select Gobo.
a) Select a gobo from the gobo wheel (000~255).
b) Activate the new value.
8) Select Gobo.rot.
a) Select a rotation mode for the selected gobo (000~255).
b) Activate the new value.
9) Select Prism.
a) Select a prism operation mode (000~255).
b) Activate the new value.
10) Select Dimmer.
a) Select a dimmer value (000~255).
b) Activate the new value.
11) Select Strobe.
a) Select a strobe mode (000~255).
b) Activate the new value.
12) Select Time.
a) Select the duration of this step (000~255).
b) Activate the new value.
13) Select Use.
a) Enable this step (Yes/No).
b) Activate the new value.
14) Repeat for the other steps.
For smoother operation of the CUSTOM program, disable all the steps that are not
part of the program (Use = No).
The fixture will execute all the steps in the CUSTOM program and it will stop.
To make the fixture to start over add a last step whose duration is 0 seconds.
Example:
Step 1: Time = 5 Use = Yes
Step 2: Time = 4 Use = Yes
Step 3: Time = 6 Use = Yes
Step 4: Time = 0 Use = Yes (This step creates a loop)
Step 5: Time = 0 Use = No
(Unused steps)
Step 255 Time = 0 Use = No
