Ecler CA series - Manual

CA series presets save and recall
page 1 / 4
ENGLISH VERSION
CA series Presets contents, save and recovery
1. Introduction
The CA series devices (CA40, CA200z) can store a total of 5 presets, or global
configuration “pictures” of the device. Once they have been saved into the CA device
memory, recalling a preset is just like changing the full CA device configuration
instantaneously, with a set of parameters’ values (volumes, EQ, etc.) that match those
ones the device had when the preset was saved. By recalling presets, the end user gets
a fast and friendly way to change the working mode of the CA device, adapting it to
different application needs.
A preset can be saved by 3 different methods:
 Using the front panel controls (except CA40)
 Using the TP‐NET third‐party protocol, from an external device (
SAVE_PRESET
)
 Using the EclerCOMM software application
And it can be recalled by 4 different methods:
 Using the front panel controls (except CA40)
 Using an external device (WPm series, for instance), connected to a 0‐10VDC
REMOTE port in the CA device
 Using the TP‐NET third‐party protocol, from an external device (
LOAD_PRESET
)
 Using the EclerCOMM software application
2. Parameters included and excluded in Presets
These are the parameters whose values are stored in a preset at the time the preset is
saved in the CA device’s memory:
 INPUTs selection (per output zone)
 INPUTs volume level, bass and treble adjustments
 OUTPUTs volume level and MUTE status
 MICROPHONE inputs Noise Gate enable/disable status
(CA40 excluded,
configured by hardware dip switches )
 MICROPHONE inputs Talkover / Pager function ON/OFF status status (
CA40
excluded, configured by hardware dip switches )
 MICROPHONE inputs Noise Gate and Talkover / Pager parameters (threshold,
attenuation, attack time, etc.)
 Panel Locked ON/OFF status (front panel hardware controls)
