Operating instructions W6E500-GJ03-01
Translation of the original operating instructions
3.2 Nominal data
Motor M6E110-EF
Phase 1~ 1~
Nominal voltage / VAC 230 230
Frequency / Hz 50 60
Type of data definition ml ml
Valid for approval /
standard CE CE
Speed / min -1 915 1015
Power input / W 270 390
Current draw / A 1.18 1.72
Motor capacitor / µF 8 8
Capacitor voltage / VDB 400 400
Max. back pressure / Pa 70 90
Min. ambient temperature
/ °C -40 -40
Max. ambient
temperature
/ °C 65 65
Starting current / A 2.3
Maximum safe operating
speed / min
-1
1920
@ 55 °C 1920
@ 55 °C
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es / % 26.6 26 30
Efficiency grade N 36.6 36 40
Power input P e / kW 0.26
Air flow q v / m³/h 3805
Pressure increase total p sf / Pa 67
Speed n / min -1 915
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 14.5 kg
Size 500 mm
Surface of rotor Coated in black
Material of terminal box PC / ABS plastic
Material of blades Press-fitted sheet steel blank, sprayed
with PP plastic
Material of wall ring Sheet steel, galvanised and coated in
black plastic (RAL 9005)
Material of guard grille Steel, coated in black plastic (RAL9005)
Number of blades 5
Direction of air flow "V"
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 54
Insulation class "F"
Humidity class F4-1
Mounting position Any
Condensate discharge
holes On rotor and stator sides
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Electrical leads Via terminal box, integrated capacitor
connected via terminal box
Motor protection Thermal overload protector (TOP)
brought out
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 61800-5-1; CE
Approval CSA C22.2 Nr.100; EAC; UL 1004-1;
VDE
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
