Operating instructions – ebm-papst W4D300-CS34-30 User Manual
Page 7
Operating instructions
W4D300-CS34-30
Translation of the original operating instructions
4.4 Connection screen
Change direction of rotation by reversing two phases
PE
green/yellow
L1
black
L2
blue
L3
brown
Y
Star connection
Item no. 11902-5-9970 · Revision 79127 · Release 2013-11-19 · Page 7 / 9
