Operating instructions W3G560-GQ41-01
Translation of the original operating instructions
3.2 Nominal data
Motor M3G112-GA
Phase 3~
Nominal voltage / VAC 400
Nominal voltage
range / VAC 380 .. 480
Frequency / Hz 50/60
Type of data definition ml
Speed / min -1 1350
Power input / W 945
Current draw / A 1.5
Min. ambient temperature
/ °C -25
Max. ambient
temperature
/ °C 60
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive Yes
Specific ratio * 1.00
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es / % 42.9 29.5 33.5
Efficiency grade N 49.4 36 40
Power input P ed / kW 0.93
Air flow q v / m³/h 7890
Pressure increase total p sf / Pa 168
Speed n / min -1 1360
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 21.8 kg
Size 560 mm
Surface of rotor Coated in black
Material of electronics
housing Die-cast aluminium, coated in black
Material of blades Aluminium sheet insert, sprayed with PP
plastic
Material of wall ring Sheet steel, pre-galvanised and coated in
black plastic (RAL 9005)
Material of guard grille Steel, coated in black plastic (RAL9005)
Number of blades 5
Blade angle -5°
Direction of air flow "V"
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 54
Insulation class "B"
Humidity class F4-1
Mounting position Shaft horizontal or rotor on bottom; rotor
on top on request
Condensate discharge
holes Rotor-side
Operation mode S1
Motor bearing Ball bearing
Technical features - Output 10 VDC, max. 10 mA
- Alarm relay
- Integrated PID controller
- Motor current limit
- PFC, passive
- Soft start
- Control input 0-10 VDC / PWM
- Control interface with SELV potential
safely disconnected from the mains
- Over-temperature protected
electronics / motor
- Line undervoltage / phase failure
detection
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Motor protection Thermal overload protector (TOP) wired
internally
Cable exit Variable
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard CE
Approval EAC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) +80 °C
Min. permissible
ambient motor temp.
(transp./storage) -40 °C
