Operating instructions – ebm-papst W3G400-CC22-51 User Manual
Page 4
Operating instructions
W3G400-CC22-51
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Direction of air flow "V"
2
Connection line PVC AWG18; 5x crimped core-end sleeves
3
Connection line PVC AWG22; 3x crimped core-end sleeves
Item no. 51110-5-9970 · ENG · Revision 82624 · Release 2014-07-28 · Page 4 / 11
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · [email protected] · www.ebmpapst.com
