Operating instructions S6E350-AN24-50
Translation of the original operating instructions
3.2 Nominal data
Motor M6E074-DF
Phase 1~ 1~ 1~ 1~
Nominal voltage / VAC 230 230 240 240
Frequency / Hz 50 60 50 60
Type of data definition ml ml ml ml
Valid for approval /
standard CE CE CE CE
Speed / min -1 910 1020 910 1040
Power input / W 75 95 80 96
Current draw / A 0.35 0.42 0.36 0.41
Motor capacitor / µF 2 2 2 2
Capacitor voltage / VDB 400 400 450 450
Capacitor standard P0 (CE) P0 (CE) P0 (CE) P0 (CE)
Max. back pressure / Pa 40 50 40 53
Min. ambient temperature
/ °C -25 -25 -25 -25
Max. ambient
temperature
/ °C 50 55 50 55
Starting current / A 0.56 0.51 0.57 0.52
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Technical features
Mass 5.2 kg
Size 350 mm
Surface of rotor Coated in black
Material of terminal box ABS plastic, black
Material of blades Press-fitted sheet steel blank, sprayed
with PP plastic
Material of guard grille Steel, phosphated and coated in black
plastic
Number of blades 5
Direction of air flow "V"
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 44; Depending on installation and
position as per EN 60034-5
Insulation class "B"
Humidity class F1-2
Mounting position Shaft horizontal or rotor on bottom; rotor
on top on request
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Electrical leads Via terminal box, integrated capacitor
connected via terminal box
Motor protection Thermal overload protector (TOP) wired
internally
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
Approval CCC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 50 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
Item no. 11669-5-9970 · Revision 80549 · Release 2014-02-14 · Page 5 / 10
