Operating instructions
S3G350-AN01-50
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Direction of air flow "V"
2
Tightening torque 0.5±0.1 Nm
3
Cable diameter: 7.5 mm; tightening torque 1.3±0.2 Nm
