Operating instructions A8D800-AD05-03
Translation of the original operating instructions
3.2 Nominal data
Motor M8D138-LA
Phase 3~ 3~ 3~ 3~
Nominal voltage / VAC 230 277 400 480
Connection Δ Δ Y Y
Frequency / Hz 60 60 60 60
Type of data definition ml ml ml ml
Valid for approval /
standard CE CE CE CE
Speed / min -1 750 800 750 800
Power input / W 1120 1270 1120 1270
Current draw / A 4.15 4.28 2.4 2.47
Max. back pressure / Pa 57 65 57 65
Min. ambient temperature
/ °C -40 -40 -40 -40
Max. ambient
temperature
/ °C 70 65 70 65
Starting current / A 5.5 12 9.5 7
Maximum safe operating
speed / min
-1
1100
@ 70 °C 1100
@ 70 °C 1100
@ 70 °C 1100
@ 70 °C
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es / % 30.9 29.3 33.3
Efficiency grade N 37.6 36 40
Power input P e / kW 0.86
Air flow q v / m³/h 11560
Pressure increase total p sf / Pa 84
Speed n / min -1 675
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 24.2 kg
Size 800 mm
Surface of rotor Cast in aluminium
Material of terminal box PC / ABS plastic
Material of blades Aluminium sheet insert, sprayed with PP
plastic
Number of blades 5
Blade angle 0°
Direction of air flow "V"
Direction of rotation Clockwise, seen on rotor
Type of protection IP 54
Insulation class "F"
Humidity class F3-1
Mounting position Any
Condensate discharge
holes On rotor and stator sides
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Electrical leads Via terminal box
Motor protection Thermal overload protector (TOP)
brought out
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60034-1 (2010); EN 61800-5-1; CE
Approval CSA C22.2 Nr.100; EAC; UL 1004-1
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
