3.2 Nominal data
Motor M6D110-EF
Phase 3~ 3~ 3~ 3~
Nominal voltage / VAC 400 400 400 400
Connection Δ Y Δ Y
Frequency / Hz 50 50 60 60
Type of data definition ml ml ml ml
Valid for approval /
standard CE CE CE CE
Speed / min -1 930 800 1050 800
Power input / W 270 190 380 250
Current draw / A 0.69 0.4 0.75 0.43
Max. back pressure / Pa 75 55 90 55
Min. ambient temperature
/ °C -40 -40 -40 -40
Max. ambient
temperature
/ °C 65 65 65 65
Starting current / A 2.5 2.3
Maximum safe operating
speed / min
-1
1920
@ 55 °C 1920
@ 55 °C 1920
@ 55 °C 1920
@ 55 °C
Phase 3~ 3~
Nominal voltage / VAC 480 480
Connection Δ Y
Frequency / Hz 60 60
Type of data definition ml ml
Valid for approval /
standard CE CE
Speed / min -1 1100 910
Power input / W 415 295
Current draw / A 0.78 0.45
Max. back pressure / Pa 100 70
Min. ambient temperature
/ °C -40 -40
Max. ambient
temperature
/ °C 65 65
Starting current / A 2.8
Maximum safe operating
speed / min
-1
1920
@ 55 °C 1920
@ 55 °C
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es / % 27.6 26 30
Efficiency grade N 37.6 36 40
Power input P e / kW 0.26
Air flow q v / m³/h 3970
Pressure increase total p sf / Pa 67
Speed n / min -1 930
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 7.5 kg
Size 500 mm
Surface of rotor Coated in black
Material of terminal box PP plastic
Material of blades Press-fitted sheet steel blank, sprayed
with PP plastic
Number of blades 5
Direction of air flow "V"
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 54
Insulation class "F"
Humidity class F4-1
Mounting position Shaft horizontal or rotor on bottom; rotor
on top on request
Condensate discharge
holes Rotor-side
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Electrical leads Via terminal box
Motor protection Thermal overload protector (TOP)
brought out
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 61800-5-1; CE
Approval CCC; EAC; VDE
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
